品牌
|
Robot Industries
|
|
Robot arm
|
RI10-1900 /10KG /1943mm
|
|
Total axis
|
7 axis (robot * 6 + rail 6 meter long * 1)
|
|
Touch Sensor
|
Yes
|
|
Arc Tracking
|
Yes
|
|
Cell Type
|
Open
|
|
Welding System
|
Mig/Mag 500A
|
|
Arm Weight
|
150 Kg
|
|
Working Radius
|
1900 mm
|
|
Repeatability
|
±0.02 mm
|
|
Basic Functions
|
Autonomous Planning; Circumferential Welding; Pendulum Welding; Intermittent Welding; Fillet Welding; Multi-layer Multi-pass Welding
|
|
Power Supply
|
380V 50/60 HZ
|
|
Optional Teaching-Free Model
|
Module Import & Non-Module Import
|
|
Optional Power
|
MIG: invermig 350 UR / 500 UR, Supermatrix 270 UR / 350 UR / 500 UR, CEA 5000; TIG: Protig 400 UR / 500 UR, Wave 315 UR, Superwave 400 UR / 500 UR; Plasma Cutters: Plasmax 120; Laser Welding:RILW 1500 BR / 2000 BR / 3000 BR / 6000 BR
|
